About the Facility


The Facility houses two 600 MHz nuclear magnetic resonance spectrometers. Each system consists of a Magnex 54 mm bore superconducting magnet operating at 14.1 Tesla, a Bruker Avance III console and a Bruker cryoplatform. Bruker TopSpin 2.1.6 software is used to control the spectrometers.


Our natural products optimized instrument is generally fitted with a 1.7 mm inverse detection triple resonance (H-C/N/D) cryoprobe with z-gradients. Sample tubes for this probe require just 35 microlitres of solution. In mass-limited situations this enables higher sample concentrations to be prepared, increasing sensitivity 14-fold compared to the standard 5 mm sample tubes. Combined with the sensitivity increase due to cryogenic cooling of the detection coil and preamplifier this instrument provides excellent sensitivity for mass-limited samples. The instrument has three channels and is generally configured for 1H and 13C detection (with 2H lock) but can be reconfigured for 1H and 15N detection.


Our biomolecular instrument has four channels and is usually fitted with a 5 mm inverse detection triple resonance (H-C/N/D) cryoprobe wth z-gradients. This configuration enables acquisition of all standard H/C/N based triple resonance experiments. The increased sensitivity afforded by the cryoprobe enables us to routinely work with sub-millimolar solutions. A BACS-60 sample changer is installed on this magnet enabling automated untended operation and screening of compound libraries.

Other probes

Other probes available for either magnet at the facility include a Protasis CapNMR inverse carbon gradient probe for analysis of tiny sample quantities, and a 5mm room temperature broadband inverse probe with z-gradients for detection of heteronuclei over the frequency range spanning from 31P to 109Ag.



Dr Brendan M. Duggan has more than 15 years of experience in small molecule and protein NMR. He started his career in NMR in Australia managing the NMR facility at the Biomolecular Research Institute for Ray Norton, then completed a PhD at the Victorian College of Pharmacy with David Craik. Moving to the US he undertook postdoctoral studies with Peter Wright at The Scripps Research Institute, before switching to industry where he was a co-author on over 70 patent applications. Most recently he managed an NMR facility at the Medical University of South Carolina in Charleston SC.
